Wheelchair Lift – Reliable Vertical Access Solution for Indoor and Outdoor Mobility
A safe and user-friendly vertical platform lift designed to provide barrier-free access for wheelchair users in homes, clinics, schools, and commercial spaces.
The Wheelchair Lift is an essential accessibility solution that enables individuals with limited mobility to move between floor levels safely and independently. Designed for both indoor and outdoor environments, this lift is ideal for residential buildings, hospitals, schools, offices, and public facilities. It features a compact footprint, easy controls, and high-level safety standards. With minimal construction requirements and fast installation, it is the perfect upgrade to make any space accessible and inclusive.
-
Designed specifically for wheelchair users
-
Load capacity: 250–400 kg
-
Travel height: Up to 3–5 meters
-
Smooth and quiet vertical movement
-
Indoor and outdoor use (weather-resistant)
-
Enclosed or open platform options
-
Safety features: anti-slip platform, emergency stop, auto ramp
-
Easy-to-use push button or remote control
-
Low pit or pitless installation
-
Suitable for homes, clinics, schools, commercial entryways
-
Capacity: 250–400 kg
-
Speed: 0.1 – 0.15 m/s
-
Travel Height: Up to 5 meters
-
Platform Size: e.g., 900×1400 mm (customizable)
-
Pit Depth: 50–100 mm or ramped (pitless)
-
Drive System: Screw-driven or hydraulic
-
Power Supply: 220V / Single-phase
-
Control: Constant pressure push buttons
-
Structure: Aluminum or powder-coated steel
-
Optional: Automatic gate, intercom, backup battery, call stations
Simple, clean design with powder-coated steel or aluminum finish. Open or enclosed cabin with transparent panels, optional roof for outdoor installations. Ramp folds automatically for easy wheelchair entry.
Optional integration with building access control, remote monitoring, and smart door systems for full accessibility experience.
